ND-SV004 Portable See Through Wall Radar System
Overview
ND-SV004 Portable See Through Wall Radar System is a newly developed ruggedized portable through wall radar, aiming at applications in security industry, e.g., protection operation, hostage rescue, indoor personnel searching.
The system can scan and detect the target area within seconds and display the accurate target number and the corresponding locations and positions in real time. Featured with high protective shell, light weight, user-friendly design, high penetration and fast response capacity, the system is an ideal solution with improved operation efficiency and outcome.
Features
• Ultra-portable and good concealment: Light weight, small size and portable design
• Superior real-time performance: No delay in detection and display
• High penetration: Able to penetrate non-metallic materials, such as concrete, soil, rock, mixed brick, etc
• High protection grade: IP67
• Multi-target detection: Able to detect and display more than 5 targets simultaneously
Complete Set
• Host
• Terminal Mobile
• Lithium Battery
• Tripod
• Tripod PTZ
• Charger
• Adapter
• Power Cable
• User Manual
Specifications
| Detection mode | Simultaneous detection of multiple moving and static targets |
| Penetrable materials | Non-metallic materials, such as concrete, soil, rock, mixed brick, floor, wood and materials with low water content |
| Numbers of detected targets | ≥5 |
| Detection distance for static targets | ≥20m (penetrate 40cm brick and concrete mixed wall) |
| Detection distance for moving targets | ≥30m (penetrate 40cm brick and concrete mixed wall) |
| Weight | 3kg (battery included) |
| Dimension | 340 x 247 x 130mm |
| Protection grade | IP67 |
See Through Wall Radar System/Wall Penetrating Radar/Through-Wall Imaging Radar
• Ultra-portable and Good Concealment
Light weight, small size and portable design
• Superior real-time performance
No delay in detection and display
• High Penetration
Able to penetrate non-metallic materials, such as concrete, soil, rock, mixed brick, etc
• High Protection Grade
IP67
• Multi-target Detection
Able to detect and display more than 5 targets simultaneously.
| • Host | x 1 |
| • Terminal Mobile | x 1 |
| • Lithium Battery | x 1 |
| • Tripod | x 1 |
| • Tripod PTZ | x 1 |
| • Charger | x 1 |
| • Adapter | x 1 |
| • Power Cable | x 1 |
| • User Manual | x 1 |
